Siemens SIMATIC C7-635 User Manual

Installing and Wiring the C7-635
3-16
C7-635 Control System
A5E00155581-04
I/O connector X10
Table 3-6 Connector Pin Assignment I/O Connector X10
Pin Name
Signal Description
1 DI+2.0 Digital input 16
2 DI+2.1 Digital input 17
3 DI+2.2 Digital input 18
4 DI+2.3 Digital input 19
5 DI+2.4 Digital input 20
6 DI+2.5 Digital input 21
7 DI+2.6 Digital input 22
8 DI+2.7 Digital input 23
9 2L+ 24 V supply voltage for DO 0.0 to 0.7
10 2L+ 24 V supply voltage for DO 0.0 to 0.7
11 2M Ground for DO 0.0 to 0.7
12 3L+ 24 V supply voltage for DO 1.0 to 1.7
13 3L+ 24 V supply voltage for DO 1.0 to 1.7
14 3M Ground for DO 1.0 to 1.7
15 1L+ 24 V supply voltage for DI 0.0 to 1.7
16 1M Ground for DI 0.0 to 2.7
