Installing and Wiring the C7-635

3-18

C7-635 Control System

A5E00155581-04

I/O Connector X 12

For the technological functions, the meaning of the outputs is described in the

columns “Counting”, “Frequency Measuring”, “Pulse Width Modulation”, “Analog

Positioning”, and Digital Positioning”.

Table 3-8 Connector Pin Assignments I/O Connector X12

Name

Signal Description Counting Frequency

Measuring

Pulse Width

Modulation

Analog

Positioning

Digital

Positioning

1 DO+0.0 Digital

output 0

Channel 0: Output – –

2 DO+0.1 Digital

output 1

Channel 1: Output – –

3 DO+0.2 Digital

output 2

Channel 2: Output – –

4 DO+0.3 Digital

output 3

Channel 3: Output – –

5 DO+0.4 Digital

output 4

– – –

6 DO+0.5 Digital

output 5

– – –

7 DO+0.6 Digital

output 6

– CONV_

Enable

power

section

–

8 DO+0.7 Digital

output 7

– – –

9 DO+1.0 Digital

output 8

– – Q0

10 DO+1.1 Digital

output 9

– – Q1

11 DO+1.2 Digital

output 10

– – Q2

12 DO+1.3 Digital

output 11

– – Q3

13 DO+1.4 Digital

output 12

– – –

14 DO+1.5 Digital

output 13

– – –

15 DO+1.6 Digital

output 14

– – –

16 DO+1.7 Digital

output 15

– – –
