Product overview
2.1 Properties
Digital output module DQ 8x24VDC/0.5A SNK BA (6ES7132-6BF61-0AA0)
12 Manual, 09/2017, A5E32855878-AB
The module has the following technical properties:
● Digital output module with 8 outputs
● Sink output (NPN, M switching)
● Supply voltage L+
● Output current 0.5 A (per channel)
● Configurable diagnostics (per module)
● Configurable substitute values (per channel)
● Suitable for solenoid valves, DC contactors, and indicator lights
The module supports the following functions:
Table 2- 1 Version dependencies of the functions
The following accessories are supplied with the module and can also be ordered separately
as spare parts:
● Labeling strips
● Color identification labels
● Reference identification label
● Shield connector
You can find additional information on the accessories in the ET 200SP Distributed I/O
System (http://support.automation.siemens.com/WW/view/en/58649293
) system manual.
