Siemens SIMATIC EP200SP User Manual

Digital output module DQ 8x24VDC/0.5A SNK BA (6ES7132-6BF61-0AA0)
Manual, 09/2017, A5E32855878-AB
13
Wiring
3
3.1
Wiring and block diagram
This section includes the block diagram of the DQ 8x24VDC/0.5A SNK BA module with the
terminal assignments for a 1-wire and 2-wire connection.
Information about wiring of the BaseUnit is available in the system manual ET 200SP
distributed I/O system (http://support.automation.siemens.com/WW/view/en/58649293
).
Note
You may use and combine the different wiring options for all channels.
Note
The load group of the module must begin with a light
-colored BaseUnit. Keep this in mind
also during the configuration.
