IM 157-1 DP (6ES7157-1AA00-0AB0)
Equipment Manual, 08/2021, A5E32100641-AE
9
Product overview
2
2.1 Properties
Article number
6ES7157-1AA00-0AB0
View of the module
Figure 2-1 View of the IM 157-1 DP interface module
