Product overview
2.3 Properties
CPU 1510SP-1 PN (6ES7510-1DJ01-0AB0)
16 Equipment Manual, 05/2021, A5E03506268-AD
– Information about communication
– PROFINET topology
– Tag status, writing tags
– Watch tables
– Memory usage
– User pages
– Data logs (if used)
– Online backup and restoration of the configuration.
– Diagnostic information for the motion control technology objects
– Display of trace recordings stored on the SIMATIC memory card
– Readout service data
– Basic Web pages
– Display of the Web server in 3 project languages, for example, comments and message
texts
– Recipes
– User-defined Web pages
• Integrated technology:
– Motion Control
The Motion Control functionality uses technology objects to support speed-controlled
axes, positioning axes, synchronous axes, external encoders, cams, cam tracks and
measuring inputs, as well as PLCopen blocks for programming the motion control
functionality.
You can find a detailed description of the use of Motion Control and its configuration in
the S7-1500 Motion Control
(https://support.industry.siemens.com/cs/ww/en/view/109751049) function manuals.
– Integrated closed-loop control functionality
- PID Compact (continuous PID controller)
- PID 3Step (step controller for integrating actuators)
- PID Temp (temperature controller for heating and cooling with two separate
actuators)
• Trace functionality:
– Trace functionality supports you in troubleshooting and optimizing the user program,
especially for motion control or closed-loop control applications. Trace only supports
saves measurements on a SIMATIC memory card. You will find additional information
on "Trace" in the Using the trace and logic analyzer function
(http://support.automation.siemens.com/WW/view/en/64897128) function manual.
