CPU 1510SP-1 PN (6ES7510-1DJ01-0AB0)
28 Equipment Manual, 05/2021, A5E03506268-AD
Technical specifications
5
The following table shows the technical specifications as of 05/2021. You will find a data
sheet including daily updated technical specifications on the Internet
(https://support.industry.siemens.com/cs/ww/en/pv/6ES7510-1DJ01-0AB0/td?dl=en).
Article number
6ES7510-1DJ01-0AB0
General information
Product type designation
CPU 1510SP-1 PN
HW functional status
FS05
Firmware version
V2.9
Product function
I&M data
Yes; I&M0 to I&M3
Module swapping during operation (hot
swapping)
Yes; Multi-hot swapping
Isochronous mode
Yes; Only with PROFINET; with minimum OB 6x
cycle of 625 µs
Engineering with
STEP 7 TIA Portal configurable/integrated
from version
V17 (FW V2.9) / V13 SP1 Update 4 (FW V1.8) or
higher
Configuration control
via dataset
Yes
Control elements
Mode selector switch
1
Supply voltage
Type of supply voltage
24 V DC
permissible range, lower limit (DC)
19.2 V
permissible range, upper limit (DC)
28.8 V
Reverse polarity protection
Yes
Mains buffering
Mains/voltage failure stored energy time
5 ms
Input current
Current consumption (rated value)
0.6 A
Current consumption, max.
0.9 A
Inrush current, max.
4.7 A; Rated value
I²t
0.14 A²·s
Power
Infeed power to the backplane bus
8.75 W
Power loss
Power loss, typ.
5.6 W
Memory
Number of slots for SIMATIC memory card
1
SIMATIC memory card required
Yes
