Siemens simatic et200sp Equipment Manual

Technical specifications
CPU 1510SP-1 PN (6ES7510-1DJ01-0AB0)
Equipment Manual, 05/2021, A5E03506268-AD
29
Article number
6ES7510-1DJ01-0AB0
Work memory
• integrated (for program)
100 kbyte
• integrated (for data)
750 kbyte
Load memory
•
Plug-in (SIMATIC Memory Card), max.
32 Gbyte
Backup
•
maintenance-free
Yes
CPU processing times
for bit operations, typ.
72 ns
for word operations, typ.
86 ns
for fixed point arithmetic, typ.
115 ns
for floating point arithmetic, typ.
461 ns
CPU-blocks
Number of elements (total)
4 000; Blocks (OB, FB, FC, DB) and UDTs
DB
• Number range
1 ... 60 999; subdivided into: number range that
can be used by the user: 1 ... 59 999, and number
range of DBs created via SFC 86: 60 000 ... 60 999
• Size, max.
750 kbyte; For DBs with absolute addressing, the
max. size is 64 KB
FB
•
Number range
0 ... 65 535
•
Size, max.
100 kbyte
FC
•
Number range
0 ... 65 535
•
Size, max.
100 kbyte
OB
• Size, max.
100 kbyte
• Number of free cycle OBs
100
• Number of time alarm OBs
20
• Number of delay alarm OBs
20
• Number of cyclic interrupt OBs
20; With minimum OB 3x cycle of 500 µs
• Number of process alarm OBs
50
• Number of DPV1 alarm OBs
3
• Number of isochronous mode OBs
1
• Number of technology synchronous alarm
OBs
2
• Number of startup OBs
100
• Number of asynchronous error OBs
4
• Number of synchronous error OBs
2

Siemens simatic et200sp Specifications

General

Category	I/O Systems
Power Supply	24 V DC
Protection Rating	IP20
Number of Modules	Up to 64 modules
Mounting	DIN Rail
Communication Protocols	PROFINET, PROFIBUS
Storage Temperature	-40 °C to +70 °C
Digital Inputs	Yes (depending on module)
Digital Outputs	Yes (depending on module)
Analog Inputs	Yes (depending on module)
Analog Outputs	Yes (depending on module)
Modularity	Modular
Relative Humidity	5 to 95% (non-condensing)
Weight	Varies by configuration
System Type	Distributed I/O
