Siemens simatic et200sp Equipment Manual

Technical specifications
CPU 1510SP-1 PN (6ES7510-1DJ01-0AB0)
30 Equipment Manual, 05/2021, A5E03506268-AD
Article number
6ES7510-1DJ01-0AB0
• Number of diagnostic alarm OBs
1
Nesting depth
•
per priority class
24
Counters, timers and their retentivity
S7 counter
•
Number
2 048
Retentivity
–
adjustable
Yes
IEC counter
• Number
Any (only limited by the main memory)
Retentivity
–
adjustable
Yes
S7 times
• Number
2 048
Retentivity
– adjustable
Yes
IEC timer
• Number
Any (only limited by the main memory)
Retentivity
– adjustable
Yes
Data areas and their retentivity
Retentive data area (incl. timers, counters,
flags), max.
128 kbyte; Available retentive memory for bit
memories, timers, counters, DBs, and technology
data (axes): 88 KB
Flag
• Size, max.
16 kbyte
• Number of clock memories
8; 8 clock memory bit, grouped into one clock
memory byte
Data blocks
• Retentivity adjustable
Yes
• Retentivity preset
No
Local data
•
per priority class, max.
64 kbyte; max. 16 KB per block
Address area
Number of IO modules
1 024; max. number of modules / submodules
I/O address area
• Inputs
32 kbyte; All inputs are in the process image
• Outputs
32 kbyte; All outputs are in the process image
per integrated IO subsystem
– Inputs (volume)
8 kbyte
– Outputs (volume)
8 kbyte

Siemens simatic et200sp Specifications

General

Category	I/O Systems
Power Supply	24 V DC
Protection Rating	IP20
Number of Modules	Up to 64 modules
Mounting	DIN Rail
Communication Protocols	PROFINET, PROFIBUS
Storage Temperature	-40 °C to +70 °C
Digital Inputs	Yes (depending on module)
Digital Outputs	Yes (depending on module)
Analog Inputs	Yes (depending on module)
Analog Outputs	Yes (depending on module)
Modularity	Modular
Relative Humidity	5 to 95% (non-condensing)
Weight	Varies by configuration
System Type	Distributed I/O
