Siemens simatic et200sp Equipment Manual

Technical specifications
CPU 1510SP-1 PN (6ES7510-1DJ01-0AB0)
34 Equipment Manual, 05/2021, A5E03506268-AD
Article number
6ES7510-1DJ01-0AB0
2. Interface
Interface types
• RS 485
Yes; Via CM DP module
• Number of ports
1
Protocols
• PROFIBUS DP master
Yes
• PROFIBUS DP slave
Yes
• SIMATIC communication
Yes
PROFIBUS DP master
•
Number of connections, max.
48; Of which 4 each reserved for ES and HMI
• Number of DP slaves, max.
125; In total, up to 256 distributed I/O devices can
be connected via AS-i, PROFIBUS or PROFINET
Services
– PG/OP communication
Yes
– Equidistance
No
– Isochronous mode
No
– Activation/deactivation of DP slaves
Yes
Interface types
RJ 45 (Ethernet)
• 100 Mbps
Yes
• Autonegotiation
Yes
• Autocrossing
Yes
• Industrial Ethernet status LED
Yes
RS 485
•
Transmission rate, max.
12 Mbit/s
Protocols
Number of connections
• Number of connections, max.
96; via integrated interfaces of the CPU and con-
nected CPs / CMs
• Number of connections reserved for
ES/HMI/web
10
• Number of connections via integrated inter-
faces
64
•
Number of connections per CP/CM
32
•
Number of S7 routing paths
16

Siemens simatic et200sp Specifications

General

Category	I/O Systems
Power Supply	24 V DC
Protection Rating	IP20
Number of Modules	Up to 64 modules
Mounting	DIN Rail
Communication Protocols	PROFINET, PROFIBUS
Storage Temperature	-40 °C to +70 °C
Digital Inputs	Yes (depending on module)
Digital Outputs	Yes (depending on module)
Analog Inputs	Yes (depending on module)
Analog Outputs	Yes (depending on module)
Modularity	Modular
Relative Humidity	5 to 95% (non-condensing)
Weight	Varies by configuration
System Type	Distributed I/O
