Technical specifications
CPU 1510SP-1 PN (6ES7510-1DJ01-0AB0)
Equipment Manual, 05/2021, A5E03506268-AD
33
Article number
6ES7510-1DJ01-0AB0
– Number of connectable IO Devices for
RT, max.
64
–
of which in line, max.
64
– Number of IO Devices that can be simul-
taneously activated/deactivated, max.
8; in total across all interfaces
–
Number of IO Devices per tool, max.
8
– Updating times
The minimum value of the update time also de-
pends on communication share set for PROFINET
IO, on the number of IO devices, and on the
quantity of configured user data
Update time for IRT
– for send cycle of 250 µs
250 μs to 4 ms; Note: In the case of IRT with
isochronous mode, the minimum update time of
625 µs of the isochronous OB is decisive
– for send cycle of 500 µs
500 μs to 8 ms; Note: In the case of IRT with
isochronous mode, the minimum update time of
625 µs of the isochronous OB is decisive
–
for send cycle of 1 ms
1 ms to 16 ms
–
for send cycle of 2 ms
2 ms to 32 ms
–
for send cycle of 4 ms
4 ms to 64 ms
– With IRT and parameterization of "odd"
send cycles
Update time = set "odd" send clock (any multiple
of 125 µs: 375 µs, 625 µs ... 3 875 µs)
Update time for RT
–
for send cycle of 250 µs
250 µs to 128 ms
–
for send cycle of 500 µs
500 µs to 256 ms
–
for send cycle of 1 ms
1 ms to 512 ms
–
for send cycle of 2 ms
2 ms to 512 ms
–
for send cycle of 4 ms
4 ms to 512 ms
PROFINET IO Device
Services
–
PG/OP communication
Yes
–
Isochronous mode
No
–
IRT
Yes
–
PROFIenergy
Yes; per user program
–
Shared device
Yes
– Number of IO Controllers with shared
device, max.
4
–
activation/deactivation of I-devices
Yes; per user program
–
Asset management record
Yes; per user program

Siemens simatic et200sp Specifications

General

Category	I/O Systems
Power Supply	24 V DC
Protection Rating	IP20
Number of Modules	Up to 64 modules
Mounting	DIN Rail
Communication Protocols	PROFINET, PROFIBUS
Storage Temperature	-40 °C to +70 °C
Digital Inputs	Yes (depending on module)
Digital Outputs	Yes (depending on module)
Analog Inputs	Yes (depending on module)
Analog Outputs	Yes (depending on module)
Modularity	Modular
Relative Humidity	5 to 95% (non-condensing)
Weight	Varies by configuration
System Type	Distributed I/O
