5 Operation
House Control and Weather Sensors - LOGO! Set 11
Entry ID: 68585346, V2.1, 09/2018
33
 Siemens AG 2018 All rights reserved
No.
Action/response
KTP700 and KTP400
8.
Close the message
window after you have
cleared all warning
messages.
KTP700
9.
If the wind speed drops
below 18 km/h and at
the same time there is
high irradiation (>20
kLUX), all blinds will
automatically close.
KTP400

Siemens SIMATIC HMI KTP400 Specifications

General

Display Type	TFT LCD
Resolution	480 x 272 pixels
Color Depth	64k colors
Operating Temperature	0 to 50°C
Storage Temperature	-20 to 60°C
Voltage Supply	24 V DC
Mounting Type	Panel Mount
Number of Keys	4 function keys
Touchscreen	Yes
Relative Humidity	10% to 90% (non-condensing)
Protection Class	IP65 (front)
Communication Interfaces	PROFINET, USB
