2 Solution
House Control and Weather Sensors - LOGO! Set 11
Entry ID: 68585346, V2.1, 09/2018
7
 Siemens AG 2018 All rights reserved
2.2.1 Components used
The application example was created with the following components:
Hardware components
Table 2-1
No.
Component
Qty
Article number
Note
1.
LOGO! 12/24RCE
1
6ED1052-1MD08-0BA0
2.
LOGO! CSM 12/24
COMPACT SWITCH MODULE
1
6GK7177-1MA20-0AA0
For the connection of the
application example to
LOGO! Set 9 or
LOGO! Set 10.
3.
LOGO!POWER 24V/4 A
1
6EP1332-1SH52
4.
SIMATIC HMI KTP400 BASIC
1
6AV2123-2DB03-0AX0
5.
Rain sensor
 "1V output voltage
-> no rain
 9V output voltage
-> rain
 Output voltage: 0-10V DC
 Operating voltage: 12-24V
DC
1
Available from specialist
retailers
e.g. Stengler rain sensor
RS-600
6.
Temperature sensor
 Measuring range:
-20°C…+40°C
 Output voltage: 0-10V DC
 Operating voltage:12-24V DC
1
Available from specialist
retailers
e.g. Stengler
temp. sensor TS-S
7.
Twilight sensor
 Measuring range:
0…255 Lux (linear)
 Output voltage: 0-10V DC
 Operating voltage:12-24V DC
1
Available from specialist
retailers
e.g. Stengler
twilight sensor DS-S
8.
Light sensor
 Measuring range:
0…40 kLux (linear)
 Output voltage: 0-10V DC
 Operating voltage: 12-24 V
DC
1
Available from specialist
retailers
e.g.: Stengler
light sensor LE-S
9.
Wind sensor
 Measuring range: 0.8..40 m/s
 Output signal: Frequency,
max. 24 V DC, 100Hz=40m/s
 Supply Voltage:
max 24V DC
1
Available from specialist
retailers
e.g.: Ventus
Mini wind gage:
Art. 200 430
Software components
Table 2-2
Component
Qty
Article number
Note
LOGO!Soft Comfort V8
1
6ED1058-0BA08-0YA1
Update V8.2 (Download)
SIMATIC WINCC BASIC V15
1
6AV2100-0AA05-0AA5

Siemens SIMATIC HMI KTP400 Specifications

General

Display Type	TFT LCD
Resolution	480 x 272 pixels
Color Depth	64k colors
Operating Temperature	0 to 50°C
Storage Temperature	-20 to 60°C
Voltage Supply	24 V DC
Mounting Type	Panel Mount
Number of Keys	4 function keys
Touchscreen	Yes
Relative Humidity	10% to 90% (non-condensing)
Protection Class	IP65 (front)
Communication Interfaces	PROFINET, USB
