Technical Data
A-2
TP 070 Equipment Manual
Release 03/00
Housing
External dimensions (W x H) 212 mm x 156 mm
Mounting cut-out (W x H) 198
–1
mm x 142
–1
mm
Mounting depth 45 mm
Degree of protection complying to EN
60529
S Front panel
S Rear panel
IP65
IP20
Weight Approx. 0.7 kg
Processor
Type 32 bit RISC
Clock frequency 66 MHz
Configuration memory
Capacity 128 kB
Software
Operating system MS WindowsR CE
Display
LCD type STN LCD/Blue mode
Active screen area (B × H) in mm 116 x 87 mm (5.7 ’’)
Resolution (horizontal x vertical) 320 x 240 pixels
Monochrome 4–level
Back-lighting CCFL tube
Half Brightness Life
1)
Approx. 50,000 h
1)
Definition, refer to glossary
Power supply
Rated voltage + 24 V DC
Permissible voltage range +18.0...+30.0 V DC
Max. permissible transients 35 V (500 msec)
Time between two transients 50 sec minimum
Power consumption
S Typical
S Switch-on current I
2
t
Approx. 0.24 A
Approx. 0.2 A
2
s
Fuse, internal Electronic
