Technical information
8.12 Scope of functions with WinCC
Comfort Panels
Operating Instructions, 07/2017, A5E36770603-AB
229
Logs
Note
The HMI devices are suitable for the logging of relatively small volumes of data.
Manage the data in several adjacent logs in a segmented circular log. The use of a large
circular log has a negative effect on performance.
Object
Specification
HMI devices
KP400 Comfort
KTP400 Comfort
KP700 Comfort to
KP1200 Comfort,
TP700 Comfort to
TP1200 Comfort
KP1500 Comfort,
TP1500 Comfort to
TP2200 Comfort
Logs
Number of logs
10
50
Number of partial logs in a
segmented circular log
400
Entries per log
1
10000
20000
50000
Filing format
CSV with ANSI character set, RDB, TXT
Storage location
• Memory card
• USB storage medium
• Network drive
1
The number of entries in the log may be restricted by the capacity of the storage medium.
Read the notes on using logs in the section "Memory concept (Page 61)".
Safety
Object
Specification
HMI devices
KP400 Comfort
KTP400 Comfort
KP700 Comfort to
KP1200 Comfort,
TP700 Comfort to
TP1200 Comfort
KP1500 Comfort,
TP1500 Comfort to
TP2200 Comfort
User view
Number of user groups
50
Number of users 50
Number of authorizations/
user permissions
32

Siemens SIMATIC HMI TP1500 Comfort Specifications

General

Flash Memory	12 MB
Supply Voltage	24 V DC
Brightness	400 cd/m²
Flash Memory Size	12 MB
Display Size	15 inches
Touch Technology	Resistive
Interfaces	Ethernet, USB
Protection Rating	IP65
Display Type	TFT
Touchscreen Type	Analog-resistive
Communication Ports	Ethernet, USB
Protection Class	IP65
