8.12 Scope of functions with WinCC
Comfort Panels
230 Operating Instructions, 07/2017, A5E36770603-AB
Infotexts
Object
Specification
HMI devices
KP400 Comfort
KTP400 Comfort
KP700 Comfort to
KP1200 Comfort,
TP700 Comfort to
TP1200 Comfort
KP1500 Comfort,
TP1500 Comfort to
TP2200 Comfort
Infotexts
Length (no. of characters)
500 (depending on font)
For alarms
Yes
For screens
Yes
For screen objects (e.g. I/O
field, switch, button, invisible
button)
Yes
Additional functions
Object
Specification
HMI devices
KP400 Comfort
KTP400 Comfort
KP700 Comfort to
KP1200 Comfort,
TP700 Comfort to
TP1200 Comfort
KP1500 Comfort,
TP1500 Comfort to
TP2200 Comfort
Screen settings Touch screen calibration
1
Brightness setting
Yes
Yes
Language change Number of languages per
project
32
VBScript User-specific extension of the
functionality
Yes
Number of scripts
50
100
200
Graphic objects
Vector and pixel graphics
Yes
Trends
Quantity
50
300
400
Task planner
Number of tasks
10
48
Text objects
Quantity
2500
40000
Direct keys PROFIBUS DP direct keys Yes
PROFINET IO direct keys
Yes
1
For HMI devices with touch screen only

Siemens SIMATIC HMI TP1500 Comfort Specifications

General

Flash Memory	12 MB
Supply Voltage	24 V DC
Brightness	400 cd/m²
Flash Memory Size	12 MB
Display Size	15 inches
Touch Technology	Resistive
Interfaces	Ethernet, USB
Protection Rating	IP65
Display Type	TFT
Touchscreen Type	Analog-resistive
Communication Ports	Ethernet, USB
Protection Class	IP65
