Technical specifications
5.4 Classification of environmental conditions
Comfort Panels INOX, ITC INOX
Compact Operating Instructions, 09/2017, A5E33472156-AI
37
5.4.3
Classification for shipping
This device exceeds requirements according to IEC 61131-2:2007 "Programmable
controllers – Part 2: Equipment requirements and tests" in terms of valid environmental
conditions.
The following specifications apply to the device when transported in the original packing.
● Mechanical environmental conditions
Standard
Title
IEC 61131-2:2007 Programmable logic controllers – Part 2:
Equipment requirements and tests
● Climatic environmental conditions
Standard
Title
IEC 60721-3-2:1997 Classification of groups of environmental parameters and their severities –
Section 2: Transportation
Class 2K1 applies with the following extensions:
• Temperature ranges:
– TP700/900 Comfort INOX: –20 … 60 °C
– TP1200 Comfort INOX: –20 … 55 °C
– TP1500 Comfort INOX: –20 … 50 °C
– TP1900 Comfort INOX, ITC1900 INOX: –20 … 45 °C
• Range of relative humidity:
– TP700/900 Comfort INOX: 10 … 90%
– TP1200/1500 Comfort INOX: 10 … 80%
– TP1900 Comfort INOX, ITC1900 INOX: 10 … 70%
The following specifications apply to the device when transported in the original packing.
The following values are derived for the significant tests from the classes stated. The testing
of the device was performed in the original packing.
Test
Value
Comment
Free fall
EN 60068-2-32
1 m 5 × free fall, in shipping
packaging
Temperature
EN 60068-2-1, test Ab
and
EN 60068-2-2, test Bb
–20 to +60 °C Cold and dry heat
Air pressure;
IEC 60068-2-13
1140 to 660 hPa Corresponds to an altitude of
–1000 to 3500 m
Humidity, relative
• TP700/900 Comfort INOX: 10 … 90%
• TP1200/1500 Comfort INOX: 10 … 80%
• TP1900 Comfort INOX, ITC1900 INOX:
10 … 70%
No condensation
Shock;
IEC 60068-2-27
250 m/s
2
, 6 ms 1000 shocks
