Technical specifications
5.4 Classification of environmental conditions
Comfort Panels INOX, ITC INOX
Compact Operating Instructions, 09/2017, A5E33472156-AI
39
Ambient temperature during operation
Temperature,
Installation in horizontal format
1
inclined, incline max. 35 0 ... 40 °C
Temperature,
Installation in portrait format
inclined, incline max. 35 0 ... 35 °C
TP1900 Comfort INOX and ITC1900 INOX: 0 ... 45 °C
2
No pressure difference inside and outside of the enclosure/control cabinet permitted
Humidity and atmospheric pressure during operation
• TP700/TP900 Comfort INOX
10 ... 90% No condensation
• TP1200/1500 Comfort INOX
10 ... 80% No condensation
• TP1900 Comfort INOX,
ITC1900 INOX
10 ... 70% No condensation
Atmospheric pressure
1
1140 to 795 hPa Corresponds to an altitude of
1
No pressure difference inside and outside of the enclosure/control cabinet permitted
Observe the Notes on use (Page 12).
In addition, observe the climate diagram in the following section and the information on the
extended inclination and ambient temperature range, see section
"Selecting a mounting position (Page 14)".
Note
System components connected to the HMI device, such as the power supply, must also be
suitable for operation under the corresponding rated conditions.
Tests for mechanical environmental conditions during operation
The following table shows the type and scope of the tests of the device with regard to
mechanical environmental conditions.
Vibration test
IEC 60068-2-6:2007-12
Test Fc
Vibration 3 axes, 10 cycles per axis
Frequency change 1 octave/min
Frequency range
5 to 8.4 Hz, deflection 3.5 mm
8.4 to 200 Hz, vibration acceleration 9.8 m/s
2
Shock test
IEC 60068-2-27:2008-02
Test Ea
3 per axis in positive and negative direction
