Technical specifications
9.2 Other configurations for IOT2050
SIMATIC IOT2050
Operating Instructions, 03/2024, A5E39456816-AF
101
Device is designed for environments with pollution degree 2
13.8 years. This was calculated under conditions of a tempera-
ture of 40 °C and a workload of 100%.
In accordance with ISO 9001
1
The device should only be connected to a power supply which meets the requirements of safe
extra low voltage (SELV) according to IEC/EN/DIN EN/UL 61010-1.
2
In the event of low supply voltage, the buffer time is reduced
Motherboard
Processor
• IOT2050 Basic: TI Sitara AM6528 GP, 1000 MHz
• IOT2050 Advance/IOT2050 M.2: TI Sitara AM6548 HS,
1000 MHz
• IOT2050 Basic: 1 GB
• IOT2050 Advance/IOT2050 M.2: 2 GB
Slot for one Micro SD card
Slot for one Nano SIM card
EMMC
• IOT2050 Basic: No
• IOT2050 Advance/IOT2050 M.2: 16 GB
IOT2050 Basic/IOT2050 Advance:
1 x mini PCIe for PCIe cards 30 x 50.59 mm or 30 x 26.8 mm
IOT2050 M.2:
• 1 x M.2 slot for E-key card 30 mm
• 1 x M.2 slot for B-key card 42 mm or 52 mm
Interfaces
USB Type A, X60 For IOT2050 Basic (FS02), IOT2050 Advance (FS04):
• X60-USB1: USB3.0 Type A
• X60-USB2: USB2.0 Type A
For IOT2050 M.2, IOT2050 Advance (FS01 ~ FS03), IOT2050
Basic (FS01):
• X60-USB1/X60-USB2: USB2.0 Type A
DisplayPort interface (DP)
Only for 6ES7647-0BA00-0YA2, 6ES7647-0BA00-1YA2 and
LAN interface
P1 - X1 LAN - P2, RJ45
1
• RS232
2
, max. 115 Kbps, D-sub connector, 9-pin
• RS422
2
3
, max. 115 Kbps, D-sub connector, 9-pin
• RS485
2 3
, max. 115 Kbps, D-sub connector, 9-pin
