Hardware descriptions
10.1 IOT2050 SM: Motherboard
SIMATIC IOT2050
108 Operating Instructions, 03/2024, A5E39456816-AF
Component/interface
Description / inscription
Meaning, comment
X17
DediProg Connector
X80
Power supply
X1500
Jumper, 3 pin, SMD
Jumper defines Flash write protection enable
or disable:
• Jumper on pins 1-2: write protection
enable
• Jumper on pins 2-3: write protection
disable
Note: When Secure Boot is not enabled, set
the flash write protection jumper in write
protection enabled state (pins 1-2) and lock
flash in bootloader during normal operation.
X103
Nano SIM Connector
X100
mini-PCIe
mini-PCIe slot
