Preparing for installation
2.3 Permitted mounting positions and mounting types
SIMATIC IOT2050 Starterkit
Product Information, 06/2021, A5E50831253-AA
9
Consider the permitted temperature range for operation that depends on the mounting
position.
Ambient temperature for operation
• Vertical: 0 to 50 °C
• Vertical: 0 to 45 °C
• Horizontal: 0 to 40 °C
Clearances
Ensure that the following clearances measurements to another component or to a wall of a
housing are complied with:
• Below the device: ≥ 50 mm
• Above the device: ≥ 50 mm
