Overview
1.1 Product description
SIMATIC IPC227G
10 Operating Instructions, 07/2022, A5E50059933-AC
Main memory
Memory expansion up to 16 GB with the following memory modules:
• 4G DDR4 SDRAM
• 8G DDR4 SDRAM
• 16G DDR4 SDRAM
The max speed of memory is up to 3200 MT/s.
The processor supports IBECC (In-Band-Error-Correction-Code), and its default value in BIOS is
"Disable".
Expandability
• 2 × M.2 Key B connector
Graphics
• Intel® UHD Graphics
Power supply
• 24 V DC (19.2 to 28.8 V)
Trusted Platform Module
(TPM)
• Without TPM
• TPM 2.0
Drives and storage media
M.2 NVMe/SATA SSD
• 256GB Eco SSD
• 240GB SSD
1
• 480GB SSD
1
M.2 Module
• Support 2 × M.2 Module on the motherboard
Coral AI Accelerator card
• Support 1 × AI Accelerator card
For detailed information, refer to SIMATIC IPC227G with AI (Page 95).
Interfaces
Ethernet
• 3 × RJ45 Ethernet 10/100/1000 Mbps
COM (optional)
• 2 × RS232/RS422/RS485
2
USB (external)
• 4 × USB 3.1 Gen2 (up to 10 Gb/s)
USB (internal)
• 1 × USB pin header to 2 USB 2.0 ports
DisplayPort
• Connection of a digital monitor, support DisplayPort Standard Version 1.4
• 2 × DP++
3
, support resolution up to 4096 × 2160 pixels at 60 Hz
Keyboard, mouse
Connection through USB port
Operating systems
Operation Systems
• Without OS
• Windows 10 Enterprise 2019 LTSC (Long Term Servicing Channel) 64-bit (MUI)
4
1
The 240G/480G SSD has the Power loss protection (PLP). For the detailed configuration,
refer to the Technical data (Page 71).
2
In the BIOS setup, you can configure support of RS232/RS422/RS485 for each COM port.
3
DP++ is a DisplayPort Dual-Mode, and it supports HDMI/DP signal output.
4
MUI: Multi-language user interface; More language packages are available on the USB
stick. You can install them according to your request.
