Overview
1.2 Design of the KTP400 Basic HMI device
KTP400 Basic, KTP600 Basic, KTP1000 Basic, TP1500 Basic
12 Operating Instructions, 08/2008, A5E01075587-01
1.2 Design of the KTP400 Basic HMI device

① Recesses for mounting clamps ⑥ Connection for functional ground
② Display / touch screen ⑦ PROFINET interface
③ Mounting seal ⑧ Power supply connector
④ Guide for labeling strips ⑨ Rating plate
⑤ Function keys ⑩ Interface name

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Siemens SIMATIC KTP600 Basic and is the answer not in the manual?

Siemens SIMATIC KTP600 Basic Specifications

General IconGeneral
Display Resolution320 x 240 pixels
TouchscreenYes
Supply Voltage24 V DC
Display TypeTFT
Display Size5.7 inches
EnclosureIP65 (front)
