Overview
1.6 Design of the KTP1000 PN Basic HMI device
KTP400 Basic, KTP600 Basic, KTP1000 Basic, TP1500 Basic
16 Operating Instructions, 08/2008, A5E01075587-01
1.6 Design of the KTP1000 PN Basic HMI device


① Display / touch screen ⑦ Rating plate
② Recesses for mounting clamps ⑧ DIP switch
③ Mounting seal ⑨ Interface name
④ Function keys ⑩ Connection for functional ground
⑤ PROFINET interface ⑪ Guides for labeling strips
⑥ Power supply connector

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Siemens SIMATIC KTP600 Basic and is the answer not in the manual?

Siemens SIMATIC KTP600 Basic Specifications

General IconGeneral
Display Resolution320 x 240 pixels
TouchscreenYes
Supply Voltage24 V DC
Display TypeTFT
Display Size5.7 inches
EnclosureIP65 (front)
