Configuring the operating system
5.6 Displaying information about the HMI device
KTP400 Basic, KTP600 Basic, KTP1000 Basic, TP1500 Basic
54 Operating Instructions, 08/2008, A5E01075587-01
5.6 Displaying information about the HMI device
1. Press the "OP" button to open the
"OP Properties" dialog.
2. Change to the "Device" tab.
The "License" tab is used to display specific
information on the HMI device. You will need
this information when contacting Technical
Support.
– "Device:" HMI device name
– "Flashsize": Size of internal flash memory
to which the HMI device image and project
data are saved. The size of internal flash
memory is not equivalent to application
memory available for a project.
– "Bootloader": Boot loader version
– "Bootl. Rel. Date": Release date of the
boot loader
– "Image": Version of the HMI device image
3. Close the dialog with "OK".
