You can 󹪝nd a data sheet including daily updated technical speci󹪝cations on the Internet
(https://support.industry.siemens.com/cs/ww/en/ps/25460).
Article number 6BK1630-1AA60-0AA0 6BK1630-2AA60-0AA0
General information  
Product type designation EC motor controller
HW functional status FS01
Product description Control of EC motors
Mean time between failures (MTBF) 100000h
Product function  
• Isochronous mode
Yes
• Four-quadrant operation
Yes
• Speed control with encoder
Yes
• Speed control without encoder
No
• Safety Functions
Yes; STO Yes; STO, SS1, SLS, SSM
Protection function  
• Undervoltage protection
Yes
• Overvoltage protection
Yes
• Overload protection
Yes
• Ground-fault protection
Yes
• Short-circuit protection
Yes
Engineering with  
• STEP 7 TIA Portal con󹪝gurable/integrated from
version
V14 SP1
Installation type/mounting  
Mounting type 35 mm rail, screw mounting
Type of ventilation Convection cooling
Supply voltage  
Design of the power supply DC
Rated value (DC) 24V
Supply voltage of the motor  
• Type of motor voltage
24 ... 48 V DC, SELV / PELV
• permissible range, lower limit (DC)
16.8V
Input current  
Current consumption (rated value) 0.5A
Current consumption, max. 1A
Current consumption for the electronics, max. 0.8A
Inrush current, max. 1.6A
Output current  
Current output (rated value) 11A
Output current, max. 22A
Output frequency 500Hz
Power loss  
Power loss, max. 25W
Digital inputs  
Technical speci󹪝cations
5.1Technical speci󹪝cations
PDC600(F)
