Dimension drawing
B
This appendix contains the dimension drawings of the SIMATIC MICRO-DRIVE PDC600 installed
on a mounting rail. You must take into account the dimensions for installation in cabinets,
control rooms, etc.
Dimension drawings of the SIMATIC MICRO-DRIVE PDC600(F)
6BK1630 -1AA6 0-0AA 0




PDC600
FigureB-1 Dimension drawings of SIMATIC MICRO-DRIVE PDC600(F), front and side view (as examples, depending on
mounting rail type used)
PDC600(F)
Equipment Manual, 12/2023, A5E50502703-AB 43
