2.3 Power supply
Infeed points
You supply the PDC at the logic unit (1L+, 2L+) and power unit (4L+) infeed points with the
following voltages:
Table 2-1 Supply voltage of PDC
Infeed
points
Nominal sup‐
ply voltage
Static supply
voltage
Dynamic supply
voltage
Maximum voltage
under fault condi‐
tions (power supply)
for maintaining elec‐
trical and functional
safety
Fusing
Logic unit
1L+, 2L+
24VDC 19.2 to 28.8V 18.5 to 30.2V
Non-periodic over‐
voltage max. 35V
for max. 500ms
with a recovery time
of 50s
Max. 42.4V Internal fusible link, not
replaceable by user.
Fusing on installation
side necessary for
through-wiring!
Installation-side two-
pole protection for
1L+/1M for SELV/PELV
with common negative
pole required for the sup‐
ply of 1L+ and 4L+.
Two-pole miniature cir‐
cuit breaker
Power unit
4L+
24 to48VDC 16.8 to 52.8V
1)
16.8 to 52.8V
1)
Max. 60V Two-pole miniature cir‐
cuit breaker
1)
When energy recovery is activated, a supply voltage above 52.8VDC (maximum value
58.8V) is also permitted. Use a suitable bi-directional supply to ensure that the voltage at
4L+ never exceeds 60VDC during operation or under fault conditions.
It is essential that you observe the information on recovery in the section "Energy
recovery" in the System Manual SIMATIC MICRO-DRIVE Drive controller PDC (https://
support.industry.siemens.com/cs/ww/en/view/109797859).
WARNING
Use separate power supply units to supply the logic unit and the power unit or a 󹪝lter between
the shared power supply unit and the power supply.
NOTICE
If you are using SELV/PELV with a common negative pole for the supply of 1L+ and 4L+, you
must insert a two-pole miniature circuit breaker (2P, 240 V AC, tripping characteristic C, rated
current 3 A, EN 60947-2) according to UL category DIVQ (UL 498) in the supply line to 1M/1L+.
You can 󹪝nd the article numbers of the miniature circuit breakers to be used in the section
"Accessories/Spare parts" in the System Manual SIMATIC MICRO-DRIVE Drive controller PDC
(https://support.industry.siemens.com/cs/ww/en/view/109797859).
