Article number 6BK1630-1AA60-0AA0 6BK1630-2AA60-0AA0
• Shock resistance during operation acc. to IEC
60068-2-27
15 g / 11 ms; for wall mounting: 5 g / 30 ms, 15 g / 11 ms
Cables  
Cable length for motor, shielded, max. 10m
Dimensions  
Width 90mm
Height 125mm; 136 mm with protective collar for PN connector
Depth 120mm
Weights  
Weight, approx. 0.65kg
Other  
Braking chopper Yes; External resistance
You can 󹪝nd information on the general technical speci󹪝cations, such as standards and
approvals, electromagnetic compatibility, protection class, etc., in the System Manual
SIMATIC MICRO-DRIVE Drive controller PDC (https://support.industry.siemens.com/cs/ww/en/
view/109774126).
5.2 Drive controller derating
The maximum permissible output current for PDCs of performance class 600 W must be reduced
as follows depending on the installation altitude, mounting position and ambient temperature.
The derating relates to the rated current of the power unit. The maximum current from the
power unit may be taken at an average speed of >10Hz (corresponds to the rotating 󹪝eld
frequency>10Hz for EC motors over a period of 20s). At frequencies <10Hz, the maximum
permissible current corresponds to the rated current of the power unit.
Derating as a function of the installation altitude
For all permissible mounting types, starting from an installation altitude of 1000 m, a derating
of 10% current per additional 1000 m elevation gain applies. In this case, the motor current and
the output current of the digital outputs must be reduced.
All other functions do not have to be reduced up to the maximum installation altitude.
The 󹪝gure below shows the maximum permitted output current as a function of installation
altitude for the derating.
Technical speci󹪝cations
5.2Drive controller derating
PDC600(F)
38 Equipment Manual, 12/2023, A5E50502703-AB
