Property Description Additional information
Braking resistor The PDC600 has no internal braking re‐
sistor. To absorb the regenerative energy
of the motor, you must connect an ex‐
ternal braking resistor or switch on the
energy recovery in the drive controller
(see p0205).
System Manual SIMATIC MICRO-DRIVE
drive controller PDC (https://
support.industry.siemens.com/cs/ww/e
n/view/109797859)

Connection of external braking resistor
(X5051)
The connection terminal (X5051) for an
external braking resistor is designed for
an average current of
15A.
Hardware STO Safety function "Hardware STO" (Safe
Torque O󹪜)
Safe torque o󹪜 via onboard terminal
(STO+ and STO-)
PROFINET
PROFINET interface with two ports
(X2050 Port 1, X2060 Port 2).
You connect PROFINET IO via the RJ45
bus connector.
System Manual SIMATIC MICRO-DRIVE
drive controller PDC (https://
support.industry.siemens.com/cs/ww/e
n/view/109797859)
The PDC600F has the additional technical properties:
Property Description Additional information
PROFIsafe Fail-safe communication via PROFINET
for controlling and evaluating the safety
functions of the drive controller.
System Manual SIMATIC MICRO-DRIVE
drive controller PDC (https://
support.industry.siemens.com/cs/ww/e
n/view/109797859)
STO (Safe Torque O󹪜) Stop function for safe torque shutdown
according to stop category 0 according
to EN60204-1
SS1 (Safe Stop 1) Stop function according to Stop Catego‐
ry 1 according to EN 60204-1 (time-
monitored)
SSM (Safe Speed Monitor) Safety speed monitoring according to
IEC/EN 61800-5-2
SLS (Safely Limited Speed) Safely limited speed according to IEC/EN
61800-5-2
Accessories
You can 󹪝nd information on the topic of "Accessories/spare parts" in the System Manual SIMATIC
MICRO-DRIVE Drive controller PDC (https://support.industry.siemens.com/cs/ww/en/view/
109797859).
