Properties
The PDC600 has the following technical properties:
Property Description Additional information
Control of EC motors The PDC600 is a motor controller for
three-phase motors (EC) with supply vol‐
tages to 48VDC and permanent mag‐
nets.
The control of DC motors is not suppor‐
ted by the PDC600.
Section Connecting the motor
(Page26).
Use in protective extra low voltage range
<42.4V/60V (SELV/PELV):
Supply voltage:
• 24VDC for the logic unit (1L+, 2L+)
• 24 V DC to 48 V DC for the power unit
(4L+)
Maximum voltage of the power supply
units under fault conditions:
• <42.4VDC for the logic unit (1L+,
2L+)
• <60VDC for the power unit (4L+)
Technical speci󹪝cations (Page35) sec‐
tion.
Current/Power Output phase current for an EC motor:
• Horizontal mounting (horizontal
mounting rail):
– Maximum 15.5A or 11A
e󹪜
– Maximum 31A or 22A
e󹪜
• Vertical mounting:
– Nominal 12.9A or 9.1A
e󹪜
– Maximum 31A or 22A
e󹪜
Typical power output with 48V supply:
• Horizontal mounting:
– Nominal 600W
– Maximum 1200W
• Vertical mounting:
– Nominal 500W
– Maximum 1200W
Technical speci󹪝cations (Page35) sec‐
tion.
Product overview
2.2Properties
PDC600(F)
Equipment Manual, 12/2023, A5E50502703-AB 13
