6.2EMC and Environmental Type Tests
Test Description Test Levels Severity
Levels
Signal Ports 2 kV (Failsafe Relay Output) 
DC Power
Ports
1.5 kV 
Dielectric Strength
AC Power
Ports
2 kV 
Signal Ports 5 kV (Failsafe Relay Output) 
DC Power
Ports
5 kV 
IEC
60255-27
HV Impulse
AC Power
Ports
5 kV 
EMC Immunity Type Tests per IEEE 1613
Note
RUGGEDCOM products meet Class 1 requirements for copper Ethernet
configurations and Class 2 for fiber Ethernet configurations. Class 1 allows for
temporary communication loss, while Class 2 requires error-free and interrupted
communications.
Description Test Levels
Enclosure Contact ± 8 kVESD
Enclosure Air ± 15 kV
Radiated RFI Enclosure Ports 35 V/m
Signal Ports ± 4 kV @ 2.5 kHz
DC Power Ports ± 4 kV
AC Power Ports ± 4 kV
Fast Transient
Earth Ground Ports ± 4 kV
Signal Ports 2.5 kV Common Mode @ 1 MHz
DC Power Ports 2.5 kV Common and
Differential Mode @ 1 MHz
Oscillatory
AC Power Ports 2.5 kV Common and
Differential Mode @ 1 MHz
Signal Ports 5 kV (Failsafe Relay)
DC Power Ports 5 kV
HV Impulse
AC Power Ports 5 kV
Signal Ports 2 kV (Failsafe Relay)
DC Power Ports 1.5 kV
Dielectric Strength
AC Power Ports 2 kV
36
RUGGEDCOM RS900
Equipment Manual, 11/2023, C79000-G8976-1024-16
