Installing the Device
2.1General Procedure
NOTICE
This product contains no user-serviceable parts. Attempted service by unauthorized
personnel shall render all warranties null and void.
Changes or modifications not expressly approved by Siemens Canada Ltd. could
invalidate specifications, test results, and agency approvals, and void the user's
authority to operate the equipment.
NOTICE
This product should be installed in a restricted access location where access can only
be gained by authorized personnel who have been informed of the restrictions and
any precautions that must be taken. Access must only be possible through the use
of a tool, lock and key, or other means of security, and controlled by the authority
responsible for the location.
2.1 General Procedure
The general procedure for installing the device is as follows:
Note
The user is responsible for the operating environment of the device, including
maintaining the integrity of all protective conductor connections and checking
equipment ratings. Make sure to review all operating and installation instructions
before commissioning or performing maintenance on the device.
1. Review the relevant certification information for any regulatory
requirements.
For more information, refer to "Approvals" (Page 35).
2. Unpack and inspect the device.
For more information, refer to "Unpacking the device" (Page 9).
3. Mount the device.
For more information, refer to "Mounting the Device" (Page 9).
4. Connect the failsafe alarm relay.
For more information, refer to "Connecting the Failsafe Alarm
Relay" (Page 13).
5. Connect power and ground the device.
For more information, refer to "Connecting Power" (Page 15).
6. Configure the device.
For more information, refer to "Configuring the Device" (Page 22).
8
RUGGEDCOM RST916C
Installation Manual, 04/2023, C79000-G8976-1490-07
