Technical Specifications
5
This section provides important technical specifications related to the device.
5.1 Power Supply Specifications
Note
When determining cable lengths, make sure the nominal input voltage for the power
supply is provided at the power source.
Input VoltagePower
Supply Type
Minimum Maximum Nominal
Internal
Fuse Rating
Isolation Maximum
Power
Consumption
a
LO 10 VDC 60 VDC 12 VDC, 24
VDC, 48 VDC
5 A 1.5 kVDC 13.4 W
88 VDC 300 VDC 125 VDC,
250 VDC
3.15 A 5 kVDC 15.3 WHI
85 VAC 264 VAC 110 VAC,
220 VAC
3.15 A 5 kVDC 15.5 W
a
Current consumption may vary based on configuration.
5.2 Failsafe Alarm Relay Specifications
Maximum Switching Voltage Rated
Switching
Current
Isolation
30 VDC 2 A
125 VDC 0.48 A
300 VDC 0.2 A
250 VAC 2 A
5.0 kVAC
a
between coil and contacts
1.0 kVAC
a
between contacts
a
50 to 60 Hz for 1 minute
RUGGEDCOM RST916C
Installation Manual, 04/2023, C79000-G8976-1490-07
29
