Siemens SIMATIC PCS 7 Manual

3-3
Connecting TM I/O to PCS 7
C79000-G8076-C710-04
Remove the cover from the expansion connector on the TPM 478-2 interface
and the cover of the expansion socket on the central module FM 456-4.
See Figure 3-1.
TPM 478-2
Expansion
connector
FM 456-4
Expansion socket
Figure 3-1 Positions of the expansion connector/socket with corresponding cover.
Removing connec-
tor/socket covers
Commissionin
g
