Connecting TM I/O to PCS 7
C79000-G8076-C710-04
4.8 Table of TELEPERM M modules for input at ”Module type”
Table 4-3
Input text for mo-
dule type
(i.a. = MLFB no.)
Module function Comment
6DS1310-8AA Interface module AG110, serial 1)
6DS1310-8AB Interface module AG110, serial 1)
6DS1318-8AB S5 interface, EG, serial 4) 5)
6DS1321-8AA Interface FBG S5-EG, parallel 1) 2)
6DS1322-8AA Interface for ES100K
6DS1327-8AA Interface to S5 E/A, ET100 1) 2)
6DS1333-8AB Interface module S5 ZG, serial 4) 5)
6DS1400-8AA S-controller 1K 5)
6DS1400-8BA S-controller 1K 5)
6DS1401-8AA K-controller 1K 5)
6DS1401-8BA K-controller 1K 5)
6DS1402-8AA S-controller 2K 5)
6DS1402-8BA S-controller 2K 5)
6DS1403-8AA K-controller 2K 5)
6DS1403-8BA K-controller 2K 5)
6DS1403-8CA K-controller 2K 5)
6DS1403-8CB K-controller 2K 5)
6DS1500-8AA Control module Motor 1K 5)
6DS1500-8BA Control module Motor 1K 5)
6DS1501-8AA Control module ESG 1K 5)
6DS1501-8AB Control module ESG 1K 5)
6DS1501-8BA Control module ESG 1K 5)
6DS1501-8BB Control module ESG 1K 5)
6DS1502-8AA Control module Motor 3K 5)
6DS1502-8BA Control module Motor 3K 5)
6DS1503-8AA Control module ESG 3K 5)
6DS1503-8BA Control module ESG 3K 5)
6DS1504-8AA Control module Valve 4K 5) 6)
6DS1505-8AA Control module Valve 8K 5) 6)
6DS1600-8AA Binary input 16 NO contact
6DS1601-8AA Binary input 48
6DS1601-8AC Binary input 48 + INT (version w 4)
6DS1601-8BA Binary input 48 + INT (version w 2)
6DS1602-8AA Binary input 32
6DS1602-8BA Binary input 32
6DS1603-8AA Binary output 32 (100 mA)
6DS1603-8AB Binary input 32 (100 mA)
6DS1603-8BA Binary output 32 (100 mA)
6DS1603-8RR Binary output 32 (100 mA)
6DS1604-8AA Binary output 16 (400 mA)
6DS1605-8AA Binary output 16 Relays
Confi
g
uration
