4-8
Connecting TM I/O to PCS 7
C79000-G8076-C710-04
Channel number This entry specifies the byte address for the
NR0xxx.Kanal input area of the S5 module.
S5-Module type Specifies the S5 module ID.
NR0xxx.S5_Typ=’xy’ .
The entry x and y can be defined with the
following values:
x = DI Digital input modules
x = AI Analog value input module
y = 1 ... 16 Entry for 1 to 16 byte for digital input
or 1 to 16 channels for analog input
(corresponds with 2 to 32 bytes)
NR0xxx.Kanal This entry specifies the byte address for the
output area of the S5 module.
NR0xxx.S5_Typ=’xy’ Specifies the S5 module ID.
The entry x and y can be defined with the
following values:
x = DQ Digital output module
x = AQ Analog value output module
y = 1 ... 16 Entry for 1 to 16 byte for digital output
or 1 to 16 channels for analog output
(corresponds with 2 to 32 bytes)
To delete the TELEPERM M slot (that is, the connection module), you must
delete the entry of the TM module in DB1 of FM456-4 and possible entries
of subordinate S5 modules in DB2 of FM456-4.
Configuring input
modules
Configuring output
modules
Deleting modules
in extended confi-
gurations
Confi
