4-11
Connecting TM I/O to PCS 7
C79000-G8076-C710-04
– Protocol 3964(R) and RK512 procedure.
The RK512 procedure is essential required. The 3964 or 3964R proto-
col is open selectable. The X5/11-12 jumper has to be set like configu-
red on the partner side [optional parameter for (R)].
S7 protocol parameter = ’Standard settings’.
When coupling to SIMATIC S7, the setting ’RK512’ includes the
’3964’ protocol. Using 3964R is recommended because of the impro-
ved communication in disturbed environment.
– Coupling to SIMATIC S7: On 6DS1333-8AB the X5/13-14 jumper has
to be set for disabling the function ’check telegram’. This is also ne-
cessary for other devices without check function.
– Coupling to SIMATIC S7-300: If the X5/13-14 jumper has been instal-
led, the 6DS1333-8AB sends the data type DAAR=n (TM_S5KS
block) for the coordination flag within the telegram array. The
P_RCV_RK S7 block then sets the flag with this number (e.g. M 0.1
for DAAR=1) after each receiving. The next telegram can be received
only, after the S7 software has reset this flag. This enabling has to be
done quickly.
Operating mode, settings for 6DS1318-8AB:
– The 6DS1318-8AB module has to be treated in the same manner as
the 6DS1333-8AB.
Confi
uration
