5-19
Connecting TM I/O to PCS 7
C79000-G8076-C710-04
Table 5-4 Available TELEPERM M I/O modules
Designation Compatible, approved
versions
MLFB
Signal modules/AE
8 AE, galvanically separated 6DS1700-8BA ...-8AA;...-8AB;...-8BB;
6DS1701-8AA;...-8AB
8 AE, not galvanically separated 6DS1730-8AA
4 AE 6DS1731-8AA ...-8RR
4 AE, + 6DS1731-8BA ...-8RR
4 EEPROM 6DS1731-8EA ...-8RR
4 + EEPROM 6DS1731-8FA ...-8RR; 6DS1713-8AB
14 Thermal elements 6DS1703-8AB ...-8RR
4 AE 6DS1731-8RR
Signal modules/AA
4 AA 6DS1702-8AA ...-8RR
Counter modules
8 channels 6DS1607-8AB
Dosing meter modules
2 or 4 channels 6DS1613-8BB -8AB
Communication modules
S5-110A, 4-channel 6DS1310-8AA
S5-110A, single-channel 6DS1310-8AB
S5-115/135/150, dual-channel 6DS1321-8AA
S5 central cabinet, dual-channel 6DS1318-8AB
6DS1333-8AB
S5 transparent, dual-channel 6DS1327-8AA
ES 100K on TM IO BUS 6DS1322-8AA
CP 581 TM 6DS1318-8AB 6DS1341-1AD;
6DS1337-1AD
Not available:
– Field multiplexer, FM driver
– Testable BI/BQ; DR; SIPART.
Interface module TPM 478-2
