Properties Description Additional information
8 DI/8 DQ (X142) The bidirectional digital inputs/outputs are assigned to
the CPU. You configure each of the digital inputs/out
puts according to your task:
• as a digital input or a digital output
• as a timer input, e.g. for measurement sensing
inputs
• as a timer output, e.g. for output cam applications
• as an oversampling input or an oversampling out
put
• for event/period duration measurement
• for pulse width modulation (PWM)
• as a high-speed output
Section Connecting (Page 43)
Accessories/spare parts
The following accessories are included in the scope of delivery of the SIMATIC Drive Controller
and can also be ordered as spare parts:
Table 3-4Spare parts
Article Article number
Bottom cover 6ES7615-0AC10-0AA0
Top cover 6ES7615-0AC10-1AA0
Spacer 6SL3064-1BB00-0AA0
Terminal kit
• 3 x I/O connector for X122/X132/X142
• 1 x 24V connector for X124
• 5 x DRIVE-CLiQ blanking cover
6SL3064-2CB00-0AA0
You can find additional information on accessories in the SIMATIC Drive Controller system
manual (https://support.industry.siemens.com/cs/ww/en/view/109766665).
3.5 Firmware functions of the CPU
The integrated SIMATIC S7-1500 TF-CPU of the SIMATIC Drive Controller supports the
following functions:
Functions
Function Description Additional information
Safety Integrated The integrated F-CPU of the SIMATIC Drive Controller processes stand
ard and safety programs on a single component. This allows fail-safe
data to be evaluated in the standard user program. As a result of the
integration, the system advantages and the extensive functionality of
SIMATIC are also available for fail-safe applications.
SIMATIC Safety - Configuring
and Programming program
ming and operating manual
(https://support.industry.
siemens.
com/cs/ww/en/view/541101
26)
