Integrated technology
Function Description Additional information
Motion control The CPU of the SIMATIC Drive Controller supports the S7‑1500 Motion
Control functions via the technology objects: speed axis, positioning
axis, synchronous axis, external encoder, cam, cam track and measur
ing input.
• Speed-controlled axis for controlling a drive with speed specifica
tion
• Positioning axis for position-controlled positioning of a drive
• Synchronous axis for interconnecting with a leading value. The
axis follows the position of the leading axis in synchronous opera
tion.
• External encoder for detecting the actual position of an encoder
and its use as a leading value for synchronous operation
• Cam, cam track for position-dependent generation of switching
signals
• Measuring input for fast, accurate and event-dependent sensing
of actual positions
You program the technology objects with Motion Control instructions
according to PLCopen.
Extended motion con
trol functions
The SIMATIC Drive Controller contains a SIMATIC S7-1500 technology
CPU. The technology CPU provides extended motion control func
tions:
• Extended synchronous operation functions
– Synchronization with specification of the synchronous posi
tion
– Actual value coupling
– Offset of leading value on following axis
– Camming
– Velocity gearing
• Up to four encoders or measuring systems as actual position for
position control
• Control of kinematics, such as
– Cartesian portals
– Roller pickers
– Delta pickers
– SCARA
• Cross-PLC synchronous operation: Coupling between leading axis
or external encoder and following axis via PROFINET IO with IRT
S7‑1500(T) Motion Control
function manuals
(https://support.industry.
siemens.
com/cs/de/en/view/1097510
49)
Integrated closed-loop
control functionality
• PIDCompact (continuous PID controller)
• PID 3Step (step controller for integrating actuators)
• PID Temp (temperature controller for heating and cooling with
two separate actuators)
PID Control function manual
(https://support.industry.
siemens.
com/cs/ww/en/view/108210
036)
Integrated safety
Function Description Additional information
Know-how protection The know-how protection protects user blocks against unauthorized
access and modifications.
SIMATIC Drive Controller sys
tem manual
29
Product overview
3.5 Firmware functions of the CPU
SIMATIC Drive Controller
Equipment Manual, 11/2022, A5E46600370-AC
