S7-1500H configuration with R1 devices in a combined topology





① CPU 1
② CPU 2
③ Two fiber-optic cables (redundancy connections)
④ Combined topology 1
⑤ Combined topology 2
⑥ IO device ET200SPHA (with system redundancy R1)
⑦ IO device ET 200SP (with system redundancy R1)
Figure 5-20S7-1500H configuration with R1 devices in a combined topology
100
S7-1500R/H redundant system
System Manual, 11/2022, A5E41814787-AD
Application planning
5.3 Configuration versions
