S7-1500R/H redundant system
System Manual, 11/2022, A5E41814787-AD
2
24V DC supply, 170
A
Access levels
Assign parameters, 238
Access levels for the CPUs, 237
Accessories, 369
Access protection for the display, 240
Access protection with the user program, 240
Ambient conditions
Operating conditions, 361
Mechanical , 361
Climatic, 362
Approvals, 351
CE, 352
cULus, 353
FM, 354
IEC 61131-2, 357
IEC 61010-2-201, 357
Asynchronous instructions, 229
Automation levels, 35
B
Backup types of the CPU data, 299
Breakpoints, 345
C
Cable length
up to 10m, 184
up to 40km, 184
Calculation of the PROFIsafe monitoring time, 210
Causes and solutions, 280
CE approval, 352
Changes previous version of system manual, 19-20
Climatic ambient conditions, 362
Coding element, 177
Power connector, 332
Commissioning, 246
Check before power-on, 246
Procedure, 247
Removing/plugging in a SIMATIC memory card,
248
First power-on, 250
First power-on, requirements, 250
Identification data, 304
Identification data, 306
Identification data - record structure, 306
Communication, 66
Communication relations in S7-1500R/H, 47
Configuration, 25
Of the redundant system S7-1500R, 25
Of the redundant system S7-1500H, 27
Of the redundant system S7-1500R, 39
Of the redundant system S7-1500H, 40
On grounded reference potential, 171
Electrical, 174
Configuration of S7-1500H and S2 devices in a
combined topology, 98
Configuration of S7-1500H with R1 devices and
backbone rings, 101
Configuration of S7-1500H with R1 devices and
switches in a line topology, 93
Configuration of S7-1500H with R1 devices and Y-
switches with DNA redundancy in line topology, 97
Configuration of S7-1500H with R1 devices and Y-
switches with DNA redundancy in the PROFINET
rings, 89
Configuration of S7-1500H with R1devices and Y-
switch in line topology, 95
Configuration of S7-1500H with R1 devices in the
PROFINET ring, 83
Configuration of S7-1500R with switches and addi
tional line topology, 79
Configuration versions of S7-1500R/H, 76
Configuring IO devices, 200
Configuring other configuration variants, 208
Configuring PROFINET rings with R1 devices, 203
Configuring the NTP server, 303
