View
The DIN rail adapter consists of a clamp, an adapter frame and a hexagon socket-head screw
with washer.
① Clamp
② Adapter frame
③ Hexagon socket-head screw
④ Washer
Figure 6-4Parts of the DIN rail adapter
160
S7-1500R/H redundant system
System Manual, 11/2022, A5E41814787-AD
Installation
6.3 Installing the standard rail adapter
