Technical data of CPU 31x
7.6 CPU 317-2 DP
CPU 31xC and CPU 31x, Technical Data
7-26 Manual, 01/2006 Edition, A5E00105475-06
Technical data
Weight 460 g
Voltages, currents
Power supply (rated value) DC 24 V
• Permissible range
20.4 V to 28.8 V
Current consumption (no-load operation) 100 mA
Making current Typically 2.5 A
I
2
t Min. 1 A
2
s
External fusing of power supply lines
(recommended)
Min. 2 A
Power loss Typically 3.5 W
7.6 7.6 CPU 317-2 DP
Technical Data
Table 7-7 Technical data for the CPU 317-2 DP
Technical Data
CPU and version
Order number 6ES7317-2AJ10-0AB0
• Hardware version
01
• Firmware version
V 2.1.0
• Associated programming package
STEP 7 as of V 5.2 + SP 1
Memory
RAM
• Integrated
512 KB
• Expandable
No
Capacity of the retentive memory for retentive
data blocks
Max. 256 KB
Load memory Plugged in with MMC (Max. 8 MB)
Buffering Guaranteed by MMC (maintenance-free)
Data storage life on the MMC
(following final programming)
At least 10 years
Execution times
Processing times of
• Bit operations
0.05 μs
• Word instructions
0.2 μs
• Fixed-point arithmetic
0.2 μs
• Floating-point arithmetic
1.0 μs
Timers/counters and their retentivity
S7 counters 512

Siemens SIMATIC S7-300 Module data Specifications

General

Series	S7-300
Manufacturer	Siemens
Protection Class	IP20
System	SIMATIC S7-300
Digital Inputs	Varies by module
Digital Outputs	Varies by module
Analog Inputs	Varies by module
Analog Outputs	Varies by module
Central Processing Unit	Varies by CPU model
Supply Voltage	24V DC or 120/230V AC
CPU Type	Varies (e.g., CPU 312, CPU 315, etc.)
Memory	Varies by CPU model
Communication Interfaces	MPI, PROFIBUS
Programming Languages	LAD, FBD, STL, SCL, GRAPH
Operating Temperature	0°C to 60°C
Storage Temperature	-40°C to 70°C
Relative Humidity	10% to 95% (non-condensing)
