Technical data of CPU 31x
7.6 CPU 317-2 DP
CPU 31xC and CPU 31x, Technical Data
7-30 Manual, 01/2006 Edition, A5E00105475-06
Technical Data
can be used for
PG communication
Reserved (default)
Configurable
Maximum 31
1
1 to 31
OP communication
Reserved (default)
Configurable
Maximum 31
1
1 to 31
S7-based communication
Reserved (default)
Configurable
Maximum 30
0
0 to 30
Routing Yes (Max. 8)
Interfaces
1st interface
Type of interface Integrated RS 485 interface
Physics RS 485
electrically isolated Yes
Interface power supply
(15 to 30 VDC)
Max. 200 mA
Functionality
MPI
Yes
PROFIBUS DP
Yes
Point-to-point connection
No
MPI
Services
PG/OP communication
Yes
Routing
Yes
Global data communication
Yes
S7 basic communication
Yes
S7 communication
As server
As client
Yes
No (but via CP and loadable FBs)
Transmission rates
Max. 12 Mbps
DP master
Services
PG/OP communication
Yes
Routing
Yes
Global data communication
No
S7 basic communication
No
S7 communication
No
Constant bus cycle time
Yes
SYNC/FREEZE
Yes
DPV1
Yes
Transmission rates Up to 12 Mbaud
