Memory concept

4.1 Memory areas and retentivity

CPU 31xC and CPU 31x, Technical Data

Manual, 01/2006 Edition, A5E00105475-06

4-7

Local data

Local data store:

• the temporary variables of code blocks

• the start information of the OBs

• transfer parameters

• intermediate results

Temporary Variables

When you create blocks, you can declare temporary variables (TEMP) which are only

available during block execution and then overwritten again. These local data have fixed

length in each OB. Local data must be initialized prior to the first read access. Each OB also

requires 20 bytes of local data for its start information. Local data access is faster compared

to access to data in DBs.

The CPU is equipped with memory for storing temporary variables (local data) of currently

executed blocks. The size of this memory area depends on the CPU. It is distributed in

partitions of equal size to the priority classes. Each priority class has its own local data area.

Caution

All temporary variables (TEMP) of an OB and its nested blocks are stored in local data.

When using complex nesting levels for block processing, you may cause an overflow in the

local data area.

The CPUs will change to STOP mode if you exceed the permissible length of local data for a

priority class.

Make allowances for local data space required for synchronous error OBs. This is assigned

to the respective triggering priority class.
