10.2 Technical Specification of the CPU 416-3 PN/DP; (6ES7416-3ER05-0AB0)
S7-400 Automation System, CPU Specifications
Manual, 10/2006, 6ES7498-8AA04-8BA0
10-27
CPU and firmware version
Dimensions
Mounting dimensions WxHxD (mm) 50x290x219
Slots required 2
Weight Approx. 0.9 kg
Voltages, currents
Current consumption from the S7-400 bus (5
VDC)
Typical 1.2 A
maximum 1.4 A
Current consumption from S7-400 bus (24 V DC)
The CPU does not consume any current at 24 V,
it only makes this voltage available at the MPI/DP
interface.
Total current consumption of the components
connected to the MPI/DP interfaces, with a
maximum of 150 mA per interface
Backup current Typical 125 µA
maximum 300 µA
Maximum backup time See
Module Specifications
reference manual,
Section 3.3.
Incoming supply of external backup voltage to the
CPU
5 to 15 V DC
Power loss Typical 5.5 W
