Connection examples for redundant I/Os
E.9 SM 326; DI 24 x DC 24 V, 6ES7 326–1BK00–0AB0
S7-400H
System Manual, 03/2012, A5E00267695-11
469
E.9 SM 326; DI 24 x DC 24 V, 6ES7 326–1BK00–0AB0
The diagram below shows the connection of one encoder to two redundant SM 326; DI 24 x
DC 24 V. The encoder is connected to channel 13.
9
9
9
9
Figure E-9 Example of an interconnection with SM 326; DI 24 x DC 24 V
