02.05 6 Wiring
© Siemens AG 1998 All Rights Reserved
FM-STEPDRIVE/SIMOSTEP (FB)
6-9
FM-STEPDRIVES
DC
+
DC
-
115
230
N
PE
MS
DC
+
DC
-
115
230
N
PE
MS
DC
+
DC
-
115
230
N
PE
MS
Mains
filter
L1
L2
L3
PE
Main filter types:
for 230 V=B84143-B8-R
Figure 6-8 Multi-axis wiring with a three-phase mains connection (230 V between phases, without neutral)
Note
The intermediate circuit connections (DC+ and DC-) of the power
controllers must not be interconnected!
Note
The mains connection cables must be shielded on both ends.
